TM1608&1609Construction ScheduleTM1608&1609Construction Schedule
| 文件编号 | 17581 | 工期 | 395天 | 开始时间 | 2016-04-19 | 结束时间 | 2017-05-18 |
| 任务数 | 87K | 整理日期 | 2019/5/17 | 下载次数 | 4102次 | ||
| 下载地址 | 计划文件点击下载(登录后才可以下载) | ||||||
计划内容
| TM1608&1609Construction Schedule | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
编号 |
Item No. |
Construction Period |
Starting date |
Finishing Date |
前置任务 |
资源名称 |
| 1 | Contract sign |
1天 | 2016-04-19 | 2016-04-19 | ||
| 2 | Effective date of the contract |
1天 | 2016-05-25 | 2016-05-25 | ||
| 3 | Design |
105天 | 2016-06-08 | 2016-09-20 | ||
| 4 | Drawings for approval |
118天 | 2016-06-28 | 2016-10-23 | ||
| 5 | Steel cutting |
1天 | 2016-07-13 | 2016-07-13 | ||
| 6 | Hull Construction |
228天 | 2016-07-13 | 2017-02-25 | ||
| 7 | Main hull Blocks fabrication |
120天 | 2016-07-13 | 2016-11-09 | ||
| 8 | Accommodation Blocks fabrication |
60天 | 2016-11-02 | 2016-12-31 | ||
| 9 | Blocks assembly |
90天 | 2016-11-09 | 2017-02-06 | ||
| 10 | Seats for equipments |
60天 | 2016-12-14 | 2017-02-11 | ||
| 11 | Support for equipments |
60天 | 2016-12-28 | 2017-02-25 | ||
| 12 | Tanks inspection |
50天 | 2017-01-04 | 2017-02-22 | ||
| 13 | NDT |
50天 | 2016-11-02 | 2016-12-21 | ||
| 14 | Air test |
50天 | 2016-11-16 | 2017-01-04 | ||
| 15 | Painting |
258天 | 2016-08-10 | 2017-04-24 | ||
| 16 | Blocks |
130天 | 2016-08-10 | 2016-12-17 | ||
| 17 | Painting defects fold up |
160天 | 2016-11-16 | 2017-04-24 | ||
| 18 | Fresh water tank |
30天 | 2017-01-11 | 2017-02-09 | ||
| 19 | Oil tank |
20天 | 2017-01-18 | 2017-02-06 | ||
| 20 | Launching |
1天 | 2017-03-15 | 2017-03-15 | ||
| 21 | Main engine(propulsion system) |
76天 | 2016-12-14 | 2017-02-27 | ||
| 22 | Seating and support |
10天 | 2016-12-14 | 2016-12-23 | ||
| 23 | Installation |
30天 | 2017-01-25 | 2017-02-23 | ||
| 24 | Commissioning |
5天 | 2017-02-23 | 2017-02-27 | ||
| 25 | Generator sets |
92天 | 2016-12-07 | 2017-03-08 | ||
| 26 | Generator seat and support |
31天 | 2016-12-07 | 2017-01-06 | ||
| 27 | Generator installaion |
5天 | 2017-01-18 | 2017-01-22 | ||
| 28 | Cables installation |
25天 | 2017-01-02 | 2017-01-26 | ||
| 29 | Commissioning |
15天 | 2017-02-22 | 2017-03-08 | ||
| 30 | Mooring winches |
96天 | 2016-12-28 | 2017-04-02 | ||
| 31 | Winches foundation |
48天 | 2016-12-28 | 2017-02-13 | ||
| 32 | Winches installation |
18天 | 2017-02-09 | 2017-02-26 | ||
| 33 | Cables installation |
16天 | 2017-02-24 | 2017-03-11 | ||
| 34 | Commissioning |
12天 | 2017-03-22 | 2017-04-02 | ||
| 35 | Anchor Winches |
138天 | 2016-12-07 | 2017-04-23 | ||
| 36 | Winches foundation |
138天 | 2016-12-07 | 2017-04-23 | ||
| 37 | Winches installation |
18天 | 2017-02-01 | 2017-02-18 | ||
| 38 | Cables installation |
16天 | 2017-02-09 | 2017-02-24 | ||
| 39 | Chain installtion |
5天 | 2017-03-01 | 2017-03-05 | ||
| 40 | Anchor installation |
2天 | 2017-03-22 | 2017-03-23 | ||
| 41 | Commissioning |
4天 | 2017-03-26 | 2017-03-29 | ||
| 42 | Sewage equipments |
93天 | 2016-11-25 | 2017-02-25 | ||
| 43 | Seat and foundation |
16天 | 2016-11-25 | 2016-12-10 | ||
| 44 | Installation |
14天 | 2016-12-13 | 2016-12-26 | ||
| 45 | Commissioning |
16天 | 2017-02-10 | 2017-02-25 | ||
| 46 | Fresh water maker and sterilizer |
92天 | 2016-11-26 | 2017-02-25 | ||
| 47 | Seat and foundation |
20天 | 2016-11-26 | 2016-12-15 | ||
| 48 | Installation |
5天 | 2016-12-21 | 2016-12-25 | ||
| 49 | Commissioning |
16天 | 2017-02-10 | 2017-02-25 | ||
| 50 | Pumps |
124天 | 2016-10-01 | 2017-02-01 | ||
| 51 | Seat and foundation |
26天 | 2016-10-01 | 2016-10-26 | ||
| 52 | Installation |
55天 | 2016-10-07 | 2016-11-30 | ||
| 53 | Commissioning |
24天 | 2017-01-09 | 2017-02-01 | ||
| 54 | Pressure tanks |
47天 | 2016-12-24 | 2017-02-08 | ||
| 55 | Seat and foundation |
12天 | 2016-12-24 | 2017-01-04 | ||
| 56 | Installation |
6天 | 2017-01-13 | 2017-01-18 | ||
| 57 | Commissioning |
17天 | 2017-01-23 | 2017-02-08 | ||
| 58 | Fans |
42天 | 2017-01-30 | 2017-03-12 | ||
| 59 | Installation |
21天 | 2017-01-30 | 2017-02-19 | ||
| 60 | Commissioning |
12天 | 2017-03-01 | 2017-03-12 | ||
| 61 | MGPS |
47天 | 2016-12-21 | 2017-02-05 | ||
| 62 | Seat and foundation |
5天 | 2016-12-21 | 2016-12-25 | ||
| 63 | Installation |
12天 | 2016-12-24 | 2017-01-04 | ||
| 64 | Commissioning |
5天 | 2017-02-01 | 2017-02-05 | ||
| 65 | AC |
58天 | 2017-02-08 | 2017-04-06 | ||
| 66 | Installation |
24天 | 2017-02-08 | 2017-03-03 | ||
| 67 | Cables connection |
12天 | 2017-02-22 | 2017-03-05 | ||
| 68 | Commissioning |
16天 | 2017-03-22 | 2017-04-06 | ||
| 69 | MSB |
88天 | 2017-01-02 | 2017-03-30 | ||
| 70 | Installation |
5天 | 2017-01-18 | 2017-01-22 | ||
| 71 | Cables connection |
25天 | 2017-01-02 | 2017-01-26 | ||
| 72 | Commissioning |
23天 | 2017-03-08 | 2017-03-30 | ||
| 73 | Outfitting items |
60天 | 2017-02-11 | 2017-04-11 | ||
| 74 | Piping supply |
33天 | 2017-02-18 | 2017-03-22 | ||
| 75 | sanitary unit |
12天 | 2017-02-11 | 2017-02-22 | ||
| 76 | Laundry equipment |
19天 | 2017-03-03 | 2017-03-21 | ||
| 77 | Room pannel |
20天 | 2017-03-10 | 2017-03-29 | ||
| 78 | Deck cover |
19天 | 2017-03-17 | 2017-04-04 | ||
| 79 | Light etc. |
33天 | 2017-03-10 | 2017-04-11 | ||
| 80 | Electrical reference |
46天 | 2017-02-26 | 2017-04-12 | ||
| 81 | Normal light |
33天 | 2017-03-10 | 2017-04-11 | ||
| 82 | FIRE ALARM / GENERAL ALARM |
12天 | 2017-03-11 | 2017-03-22 | ||
| 83 | NAVIGATION / WIRELESS EQUIPMENT |
6天 | 2017-03-17 | 2017-03-22 | ||
| 84 | INNER COMMUNICATION EQUIPMENT |
12天 | 2017-04-01 | 2017-04-12 | ||
| 85 | CONTROL BOX |
26天 | 2017-02-26 | 2017-03-23 | ||
| 86 | Sea trial |
8天 | 2017-04-27 | 2017-05-04 | ||
| 87 | Delivery |
2天 | 2017-05-17 | 2017-05-18 |
局部效果预览，详细内容请下载附件查看
